Durable Hose

Basic Info.

Model NO.	Durable Fire Hose
Hose Coupling Type	Hose Coupling
Fire Hose Length	15m,20m,25m,30m
Working Pressure	13bar,16bar,20bar,25bar
Diameter	25mm,40mm,50mm,65mm,80mm,100mm
Lining	With Lining
Weaving Type	Twill Weaving
Hose Coupling Structure	Plug-in
Color	White
Product Name	Durable Hose
Brand Name	Xhyxfire
Text	Customizable
Transport Package	Carton
Specification	1"/1.5"/2"/2.5"/3"/4"/6′′/8′′
Trademark	XHYXFIRE
Origin	China
HS Code	5909000000
Production Capacity	2000 Rolls Per Month

Product Description

Durable Hose - Customizable Features From Xhyxfire for Every Use

Quick Details

I.D.		Service Pressure	Burst Pressure
Inch	mm	(PSI/Bar)	(PSI/Bar)
1½″	38	250/17 300/21 400/28	750/51 900/63 1200/84
1¾″	45
2″	50
2½″	65
2¾″	70
3″	75
4″	102

Product Details

Brand Name:

XHYXFire

Model Number:

XF-Q-789

Length:

As Per Requirement

Material:

Premium PVC/TPU

Lattice:

High-Intensity Polyester Short-Fiber

Type:

Fire Fighting Equipment

Use:

Ideal for Fire Fighting and Agricultural Applications

Reinforcement:

Robust Polyester Woven Jacket

Application:

Perfect for Fire Fighting and Emergency Rescue Scenarios

Feature:

Built with High Pressure, High Abrasion, and Ozone Resistance

Lining:

Durable Rubber Fire Hoses

Our rubber lining fire hose is expertly crafted with a polyester jacket and rubber lining. The polyester jacket features a warp of polyester staple and weft of polyester filament, while the lining is made from natural rubber. This hose is exceptionally flexible and capable of withstanding high pressure. It boasts excellent rolling and aging resistance. A special adhesive is applied between the jacket and rubber lining, significantly enhancing the adhesive strength, ensuring the rubber lining remains intact even after prolonged use.

The main features: Lightweight, flexible, with superior adhesive strength and prolonged service life.

Fire Fighting Hose with John Morris BS Fire Hose Coupling Technical Parameter
1) The fire hose lining options include PVC, Rubber, or Copy Rubber. The jacket is skillfully woven from high-intensity polyester filament or short-fiber (twill/plain). 2) A special adhesive (solid or liquid) is placed between the jacket and hose for enhanced bonding. The canvas hose is soft and highly polished, minimizing flow resistance. 3) This fire hose is made thinner and softer, yet lightweight and more user-friendly. 4) It exhibits high pressure resistance, low temperature resistance, anti-corrosion, aging resistance, and wear-resistance. 5) Available in numerous lining colors: blue, black, transparent, etc., or tailored to your specifications. 6) Lengths range from 10m - 30m, customizable to suit your needs. 7) Packaging is done in poly bags and cartons for secure distribution. 8) Certified quality with ISO9001:2015 guarantee. 9) Suitable for use in both fire fighting and agriculture.
